DFM -32-80-P-A-GF

ZLL(ZQC)

DFM -32-80-P-A-GF

delivery time:in stock

• Distance of centre of gravity of payload to yoke plate xs50 mm
• Stroke80 mm
• Piston diameter32 mm
• Drive unit operating modeYoke
• CushioningElastic cushioning rings/pads at both ends
• Mounting positionAny
• GuideSliding guide
• Structural designGuide
• Position sensingFor proximity sensor
• Symbol00991737
• Operating pressure0.15 MPa ... 1 MPa
• Operating pressure1.5 bar ... 10 bar
• Max. speed0.8 m/s
• Mode of operationDouble-acting
• Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4]
• Information on operating and pilot mediaOperation with oil lubrication possible (required for further use)
• Corrosion resistance class (CRC)1 - Low corrosion stress
• LABS (PWIS) conformityVDMA24364-B1/B2-L
• Ambient temperature-20 °C ... 80 °C
• Impact energy in the end positions0.4 J
• Max. force Fy1227 N
• Max. force Fy static1227 N
• Max. force Fz1227 N
• Max. force Fz static1227 N
• Max. torque Mx47.84 Nm
• Max. static moment Mx47.84 Nm
• Max. torque My35.57 Nm
• Max. static moment My35.57 Nm
• Max. torque Mz35.57 Nm
• Max. static moment Mz35.57 Nm
• Max. permissible torque load Mx as a function of the stroke8.01 Nm
• Max. payload as a function of the stroke at defined distance xs166 N
• Theoretical force at 6 bar, retracting415 N
• Theoretical force at 6 bar, advancing482 N
• Moving mass1450 g
