Delivery time:6-10 weeks
| Product characteristics | |
|---|---|
| Electrical design | PNP |
| Output function | normally open |
| Sensing range [mm] | 5 |
| Housing | Threaded type |
| Dimensions [mm] | M18 x 1 / L = 80 |
| Electrical data | |
| Operating voltage [V] | 10...36 DC |
| Current consumption [mA] | 15; (24 V) |
| Protection class | II |
| Reverse polarity protection | yes |
| Outputs | |
| Electrical design | PNP |
| Output function | normally open |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 250 |
| Switching frequency DC [Hz] | 500 |
| Short-circuit protection | yes |
| Type of short-circuit protection | yes (non-latching) |
| Overload protection | yes |
| Monitoring range | |
| Sensing range [mm] | 5 |
| Real sensing range Sr [mm] | 5 ± 10 % |
| Operating distance [mm] | 0...4.05 |
| Accuracy / deviations | |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2 |
| Hysteresis [% of Sr] | 1...15 |
| Switch-point drift [% of Sr] | -10...10 |
| Operating conditions | |
| Ambient temperature [°C] | -25...80 |
| Protection | IP 67 |
| Tests / approvals | |
| EMC | |
| MTTF [years] | 1884 |
| Mechanical data | |
| Weight [g] | 163 |
| Housing | Threaded type |
| Mounting | flush mountable |
| Dimensions [mm] | M18 x 1 / L = 80 |
| Thread designation | M18 x 1 |
| Material | brass white bronze coated; sensing face: PC |
| Displays / operating elements | |
| Display | |
| Accessories | |
| Items supplied | |
| Remarks | |
| Pack quantity | 1 pcs. |
| Electrical connection | |
| Connection | Cable: 2 m, PVC; 3 x 0.5 mm² |
