| Product characteristics | |
|---|---|
| Type of light | red light |
| Housing | rectangular |
| Application | |
| System | polarization filter |
| Function principle | Retro-reflective sensor |
| Electrical data | |
| Operating voltage [V] | 10...30 DC |
| Current consumption [mA] | < 22 |
| Protection class | III |
| Reverse polarity protection | yes |
| Type of light | red light |
| Wave length [nm] | 660 |
| Outputs | |
| Electrical design | PNP |
| Output function | light-on/dark-on mode; (programmable) |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 200 |
| Switching frequency DC [Hz] | 2000 |
| Short-circuit protection | yes |
| Type of short-circuit protection | yes (non-latching) |
| Overload protection | yes |
| Monitoring range | |
| Range referred to prismatic reflector [m] | 0...2; (Prismatic reflector Ø 80 E20005) |
| Range adjustable | yes |
| Max. light spot diameter [mm] | 64 |
| Light spot dimensions refer to | at maximum range |
| Polarization filter available | yes |
| Operating conditions | |
| Ambient temperature [°C] | -25...60 |
| Protection | IP 67 |
| Tests / approvals | |
| EMC | |
| MTTF [years] | 854 |
| Mechanical data | |
| Weight [g] | 40 |
| Housing | rectangular |
| Dimensions [mm] | 35 x 11 x 24 |
| Material | housing: ABS; LED window: SEPS; pushbutton: SEPS |
| Lens material | |
| Lens alignment | Side sensing |
| Displays / operating elements | |
| Display | |
| Electronic lock | yes |
| Accessories | |
| Items supplied | |
| Remarks | |
| Remarks | |
| Pack quantity | 1 pcs. |
| Electrical connection | |
| Connection | Connector: 1 x M8; coding: A |
| Diagrams and graphs | |
| excess gain graph |
|
