Capacitive proximity switch KI5085
Delivery time: Temporarily available in stock (order period 12-14 weeks)
Product characteristics
|
Electrical design
|
PNP
|
|
Output function
|
normally open / normally closed; (selectable)
|
|
Sensing range [mm]
|
8
|
|
Communication interface
|
IO-Link
|
|
Housing
|
threaded type
|
|
Dimensions [mm]
|
M30 x 1.5 / L = 90
|
Electrical data
|
Operating voltage [V]
|
10...30 DC; (10...36 DC (60 °C))
|
|
Current consumption [mA]
|
< 18
|
|
Protection class
|
III
|
|
Reverse polarity protection
|
yes
|
|
Measuring principle
|
capacitive
|
Outputs
|
Electrical design
|
PNP
|
|
Output function
|
normally open / normally closed; (selectable)
|
|
Max. voltage drop switching output DC [V]
|
2.5
|
|
Permanent current rating of switching output DC [mA]
|
100
|
|
Switching frequency DC [Hz]
|
10
|
|
Short-circuit proof
|
yes
|
|
Overload protection
|
yes
|
Accuracy / deviations
|
Hysteresis [% of Sr]
|
1...15
|
|
Switch point drift [% of Sr]
|
-20...20
|
Interfaces
|
Communication interface
|
IO-Link
|
|
Transmission type
|
COM1 (4,8 kBaud)
|
|
IO-Link revision
|
1.1
|
|
SDCI standard
|
IEC 61131-9 CDV
|
|
Profiles
|
Smart Sensor
|
|
SIO mode
|
yes
|
|
Min. process cycle time [ms]
|
101
|
|
Supported DeviceIDs
|
|
Type of operation
|
DeviceID
|
|
Default
|
388
|
|
Operating conditions
|
Ambient temperature [°C]
|
-25...80
|
|
Protection
|
IP 65; IP 67
|
Tests / approvals
|
EMC
|
|
EN 61000-4-2 ESD
|
8 kV AD
|
|
EN 61000-4-3 HF radiated
|
10 V/m
|
|
EN 61000-4-4 Burst
|
2 kV
|
|
EN 61000-4-6 HF conducted
|
3 V
|
|
EN 55011
|
class B
|
|
|
Vibration resistance
|
|
EN 60068-2-6 Fc
|
(10...55 Hz) / 1 mm amplitude, oscillation period 5 min., 30 min. per axis at resonance or 55 Hz
|
|
|
Shock resistance
|
|
EN 60068-2-27 Ea
|
30 g 6 shocks / 11 ms half-sine (x, y, z)
|
|
|
MTTF [years]
|
719
|
Mechanical data
|
Weight [g]
|
128.8
|
|
Housing
|
threaded type
|
|
Mounting
|
flush mountable
|
|
Dimensions [mm]
|
M30 x 1.5 / L = 90
|
|
Thread designation
|
M30 x 1.5
|
|
Materials
|
housing: stainless steel (1.4404 / 316L); pushbuttons: TPE-U; cover: PBT; LED window: PEI
|
Displays / operating elements
|
Display
|
|
switching status
|
1 x LED, yellow
|
|
|
Teach function
|
yes
|
|
Electronic lock
|
yes
|
Electrical connection - plug
|
Connection
|
Connector: 1 x M12; coding: A
|
