ZLL(YMX)
WLL190T-2P434
delivery time:in stock
| Supply voltage | 10 V DC ... 24 V DC 1) |
| Ripple | ≤ 10 % 2) |
| Current consumption | 50 mA |
| Switching output | PNP 3) 4) |
| Switching mode | Light/dark switching 3) 4) |
| Switching mode selector | Manually selectable |
| Response time |
≤ 2 ms ≤ 60 µs ≤ 250 µs |
| Switching frequency |
8,333 Hz 2,000 Hz 250 Hz |
| Time functions |
Without time delay Off delay On delay One shot |
| Delay time | Programmable, 0 ms ... 9,999 ms |
| Connection type | Male connector M8, 4-pin |
| Circuit protection |
A 5) B 6) C 7) D 8) |
| Protection class | III |
| Weight | 25 g |
| Housing material | Plastic, ABS/PC |
| Enclosure rating | IP66 9) |
| Ambient operating temperature | –25 °C ... +55 °C 10) |
| Ambient temperature, storage | –40 °C ... +70 °C |
