ZXG
FSDS-XAN
Delivery date: stock
| socket | T-32A |
| series | 2 |
| Flow capacity | 12 - 60 L/min. |
| Maximum operating pressure | 350 bar |
| Split accuracy at minimum flow input | 50% ±4.5% |
| Shunt accuracy at maximum flow input | 50% ±2.5% |
| Pressure drop at minimum input flow | 2 bar |
| Pressure drop at maximum input flow | 24 bar |
| The valve head is fitted with a hexagonal size | 28,6 mm |
| Valve mounting torque | 61 - 68 Nm |
| Model weight | 0.27 kg. |
| Seal kit - Cartridge | Buna: 990032007 |
| Seal kit - Cartridge | Polyurethane: 990032002 |
| Seal kit - Cartridge | Viton: 990032006 |
