| Product characteristics | |
|---|---|
| Electrical design | PNP |
| Output function | normally open |
| Sensing range [mm] | 4 |
| Housing | Threaded type |
| Dimensions [mm] | M12 x 1 / L = 45 |
| Application | |
| System | gold-plated contacts; Increased sensing range |
| Application | regular cleaning processes |
| Electrical data | |
| Operating voltage [V] | 10...36 DC |
| Current consumption [mA] | 10; (24 V) |
| Protection class | II |
| Reverse polarity protection | yes |
| Outputs | |
| Electrical design | PNP |
| Output function | normally open |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 100 |
| Switching frequency DC [Hz] | 800 |
| Short-circuit protection | yes |
| Type of short-circuit protection | yes (non-latching) |
| Overload protection | yes |
| Monitoring range | |
| Sensing range [mm] | 4 |
| Operating distance [mm] | 0...3.25 |
| Increased sensing range | yes |
| Accuracy / deviations | |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
| Hysteresis [% of Sr] | 1...20 |
| Operating conditions | |
| Ambient temperature [°C] | 0...100 |
| Protection | IP 68; IP 69K; ("COP") |
| Tests / approvals | |
| EMC | |
| MTTF [years] | 1676 |
| UL approval | |
| Mechanical data | |
| Weight [g] | 27 |
| Housing | Threaded type |
| Mounting | flush mountable |
| Dimensions [mm] | M12 x 1 / L = 45 |
| Thread designation | M12 x 1 |
| Material | threaded sleeve: stainless steel (1.4404 / 316L); sensing face: PEEK; lock nuts: stainless steel |
| Displays / operating elements | |
| Display | |
| Accessories | |
| Items supplied | |
| Remarks | |
| Pack quantity | 1 pcs. |
| Electrical connection - plug | |
| Connection | Connector: 1 x M12; coding: A; Contacts: gold-plated |
