ElectricalContact function
2 CO
ElectricalRated operational voltage [Ue]
250 V AC
ElectricalRated frequency [f]
50/60 Hz
ElectricalRated current [Ie ]
4 A
ElectricalConventional free air thermal current [Ith]
4 A
ElectricalRated operational currentAC--13250 V [Ie ]
3 A
ElectricalRated operational currentAC-15 [Ie]
2 (250 V AC) A
ElectricalMinimum operating voltage per contact [Umin]
5 V DC
ElectricalRated impulse withstand voltage [Uimp]
2.5 kV
MechanicalMounting width
8.8 (0.5 SU) mm
MechanicalDegree of protectionIntegrated
IP40
MechanicalTerminals
Lift terminals
MechanicalTightening torque of terminal screws
≦ 1.0 Nm
Standards
EN 45545-2; IEC 61373
