AC5222
delivery time：2 weeks
Product characteristics
Number of inputs and outputs
Number of analogue inputs: 2
Application
Application
field installation
Electrical data
Operating voltage [V]
26.5...31.6 DC
Max. current consumption from AS-i [mA]
250
Reverse polarity protection
yes
Inputs / outputs
Number of inputs and outputs
Number of analogue inputs: 2
Inputs
Sensor supply of the inputs
AS-i
Number of analogue inputs
2; (connection of 2- and 3-wire sensors)
Analogue input (current) [mA]
4...20
Max. voltage drop across load for nominal voltage [V]
10
Analogue inputs protected against short circuits
yes
Resolution of analogue input
12 bit
Accuracy / deviations
Accuracy
0.5; (% of the final value of the measuring range; tolerance under the influence of electromagnetic interference: < ± 1 % of the final value of the measuring range)
Operating conditions
Ambient temperature [°C]
-25...70
Storage temperature [°C]
-25...70
Max. relative air humidity [%]
90; (non condensing)
Max. height above sea level [m]
2000
Protection
IP 67
Tests / approvals
EMC
MTTF [years]
174
UL approval
AS-i classification
AS-i version
2.11; 3.0
AS-i addressing
addressing socket
Extended addressing mode
no
AS-i profile
S-7.3.D
AS-i I/O configuration [hex]
7
AS-i ID code [hex]
3.D
Mechanical data
Weight [g]
176
Materials
PA; piercing contacts: CuSn6 nickel-plated and tin-plated
Displays / operating elements
Display
Electrical connection
Module connection
Flachkabel
Accessories
Items supplied
Accessories (optional)
Remarks
Remarks
Pack quantity
1 pcs.
