D91FBB32HC4NS00
1
  • D91FBB32HC4NS00
2
views: 26

D91FBB32HC4NS00

Rate:
0.0000/5

( 0 reviews )

Item NO.: V028398 MOQ: 0
Weight:    22kgs
Package Size:
 Price:
$2356.00
 Qty:
      $2356.00
 Shipping:   Calculate Shipping Cost

ZZ

D91FBB32HC4NS00

delivery time:4 months



Technical Specifications
Port Connection:NG25 / CETOP 08
Flow Rate:400 L/Min
Spool Position:Operated in position a or b
Pilot Inlet / Drain Locations:Internal / internal
Seal Material:NBR
Signal Input:4 - 20 mA
Flow Direction:12 - 20 mA = P-A
Valve Option:Standard
Connection Type:6 + PE
Spool Code:B32
Operation Type:Pilot
Actuation Type:Proportional solenoid
Function:3-way
Maximum Flow Rate:N/A
Maximum Operating Pressure:350 bar
Maximum Operating Temperature:60 °C
Minimum Operating Temperature:-20 °C
For Fluid Type:Hydraulic oil according to DIN 51524 ... 535, Water glycol
Weight:21.1 kg
Product Series:Proportional DC valve
Mounting Type:Subplate mounting
Seal Material:NBR
