Model |
ZJ30/1700CZ |
|
Drilling Depth (ft) (41/2″DP) |
10000 |
|
Workover Depth (ft) (31/2″DP) |
21000 |
|
Max Hook Load (lbf) |
400000 |
|
Hook speed (ft/s) |
0.65～4.59 |
|
Mast height (ft) |
118/125 |
|
Mast type |
Mast or Erection |
|
Engine power (hp) |
2×540 |
|
Hydraulic transmission box |
2×S5610HR |
|
Drive ways |
Hydraulic + mechanical |
|
Traveling system |
6×5 |
|
Drilling line diameter (in) |
1 1/4” |
|
Hook block |
YG180 |
|
Swivel |
SL225 |
|
Rotary table |
ZP205/ZP275 |
|
Chassis |
XD70/14×8 |
|
Approaching /Departure angle |
26°/18° |
|
Min. ground clearance (in) |
12 |
|
Max. gradient ability |
26% |
|
Min. turning diameter (ft) |
135 |
|
Overall dimension (ft) |
73×10×15 |
|
Main unit mass (lbs) |
170000 |
|
Mass of accessories (lbs) |
～70000 |
